Side Entry (Multi port available)
End Entry

75psi

2000psi

The design is qualified by building a prototype vessel that is subjected to 100,000 cycles over a pressure range of atmospheric pressure to that of the design pressure. Then the prototype vessel that is cycle tested is subjected to hydrostatic qualification test and the prototype vessel has to withstand a pressure not less than SIX times the design pressure.

1 membrane of 40" /21"/14" length can be assembled into one 2.5-inch pressure vessel.
(For more than 1 membranes please contact your First Line representative)

6 membranes of 40" length can be assembled into one 4-inch pressure vessel.
(For more than 6 membranes please contact your First Line representative)

7 membranes of 40" length can be assembled into one 8-inch pressure vessel.
(For more than 8 membranes please contact your First Line representative)

1/4" Rc

1/4" NPT

1/4" BSP

(For other requirements please contact your First Line representative)

For 300/450psi pressure vessels
     End Port : 1/2 ″NPT F or 3/4 ″NPT F
     Side Port : 1 ″ Grooved

For 600/1000/1200psi pressure vessels
     End Port : 3/4 ″NPT F
     Side Port : 1 ″ Grooved
